Steel Structure Factory
Created with Pixso. Customized Steel Structure Factory Galvanized Prefab Building Construction

Customized Steel Structure Factory Galvanized Prefab Building Construction

Brand Name: YDX
Model Number: YDX-00
MOQ: 1-10000 square meters
Price: $35.00-$63.00
Delivery Time: 20-30 works days
Payment Terms: T/T
Detail Information
Place of Origin:
CHINA,QINGDAO
Certification:
CE ISO SGS
Main Frame::
Q355 Q235
Window::
Aluminum Alloy Window
Door::
Sliding Door, Rolling Door
Wall & Roof::
Sandwich Panel; Color Steel Sheet
Secondary Structure::
Purlin; Brace, Knee Brace Etc
Cladding::
PU/Rock Wool/Fiberglass/EPS
Column & BeamConnection::
High Strength Bolt
Advantage::
Easy & Fast Install
Packaging Details:
Exported standard packing
Supply Ability:
10000 tons/month
Highlight:

Customized Steel Structure Factory

,

Steel Structure Factory Galvanized

,

Galvanized Prefab Building Construction

Product Description

Galvanized Prefab Building Customized Design Construction Steel Structure Factory

Advantages of Steel Structure Workshops in Modern Architecture

Steel structure workshops possess multiple unique advantages, making them the preferred building type in industrial, commercial, and storage fields. Below is a detailed explanation of their main strengths:

1. High Strength and Durability

· Properties of Steel: Steel boasts high strength, toughness, and tensile performance, enabling it to withstand significant loads and impacts.

· Long Service Life: With anti-corrosion and fire-resistant treatments, steel structure workshops can last over 50 years or even longer.

· Resistance to Natural Disasters: Steel structures exhibit excellent seismic and wind resistance, making them suitable for earthquake-prone or high-wind areas.

2. Fast Construction and High Efficiency

· Prefabricated Production: Steel components are prefabricated in factories, and on-site assembly significantly shortens the construction cycle.

· Modular Design: Standardized designs simplify the construction process, reducing labor and time costs.

· Weather-Resistant Construction: Construction is less affected by weather conditions, allowing year-round progress and ensuring timely project completion.

3. High Space Utilization and Flexible Design

· Large-Span Design: Steel structure workshops can achieve large-span, column-free spaces, providing greater usable area and higher space efficiency.

· Adaptable Layout: Internal layouts can be adjusted to meet various functional needs, such as production lines, storage, or office spaces.

· Strong Expandability: Future expansions are easy to implement, allowing steel structure workshops to adapt to enterprise growth.

4. Eco-Friendly and Sustainable Development

· Recyclable Materials: Steel is 100% recyclable, reducing construction waste and aligning with green building principles.

· Energy-Efficient Design: Insulation materials and natural lighting designs can reduce energy consumption and operational costs.

· Minimal Pollution: Construction generates less noise and dust, minimizing environmental impact.

5. High Cost-Effectiveness and Low Comprehensive Costs

· Optimized Material Usage: Steel quantities can be precisely controlled based on design, reducing waste.

· Low Maintenance Costs: Steel structure workshops require minimal maintenance, resulting in lower long-term expenses.

· High Comprehensive Benefits: Although initial investments may be higher, the durability and low maintenance costs make steel structures more economical in the long run.

Summary

With their high strength, fast construction, flexible design, eco-friendliness, and cost-effectiveness, steel structure workshops have become a mainstream choice in modern architecture. Whether for industrial plants, storage facilities, or commercial buildings, steel structure workshops meet diverse needs, providing enterprises with efficient and sustainable solutions.

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard  Bolt, Self-tapping nail etc
