| Brand Name: | YDX |
| Model Number: | YDX-SDG |
| MOQ: | 50-10000 square meters |
| Price: | $35.00-$63.00 |
| Delivery Time: | 20-30 works days |
| Payment Terms: | T/T |
High Strength Steel Structure Workshop Prefabricated Q355 Carbon Kits
Steel structure buildings denote edifices primarily constructed with steel components—beams, columns, and steel sheets—recognized for their structural integrity, resilience, and versatility. These architectural entities epitomize load-bearing efficiency, owing to steel's high strength-to-weight ratio and ductility, enabling expansive, open interiors. Renowned for adaptability and longevity, they offer tailored design configurations for diverse applications in residential, commercial, and industrial sectors. Esteemed for their seismic resilience and sustainable attributes, steel structures align with contemporary architectural paradigms, representing an amalgamation of engineering prowess and design ingenuity, symbolizing the pinnacle of modern construction methodologies.
| Product Application | |||
| Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse | |||
| A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding! | |||
| An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework. | |||
| SPECIFICATION FOR STEEL STRUCTURE BUILDING | |||
| Main Steel Frame | Steel Column & Beam | 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel | |
| 2. Surface: Hot Dip Galvanized or Painted; | |||
| 3. Connection: All Bolts Connection; | |||
| Supporting System | Roof Purlin | C or Z Section Steel, Q235B | |
| Wall Purlin | C or Z Section Steel, Q235B | ||
| Bracing | Steel Rod, Q235B | ||
| Cross Support | Steel Rod, Q235B | ||
| Column Support | Angle Steel; Steel Rod; Q235B | ||
| Angle Brace | Angle steel,Q235B | ||
| Tie Bar | Steel Pipe,Q235B | ||
| Roof & Wall System | 1. Single Colorful Corrugated Steel Sheet; Thickness: 0.3-0.8mm |
||
| 2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU; Thickness: 50-150mm; |
|||
| Accessories | Door | Sliding; Rolled Up Door (Manual/Auto) | |
| Window | Aluminum Alloy; PVC; | ||
| Downspout | PVC pipe; | ||
| Gutter | Galvanized Steel Sheet; Stainless Steel | ||
| Ventilator | Stainless Steel Turbine Ventilator | ||
| Skylight Belt | FRP or PC semi-transparent Skylight Belt | ||
| Flash | Color Steel Sheet | ||
| Fittings | Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc | ||
Our Service
1. We own the factory with advanced equipment and well trained workers.
2. We control the cost for every step of production to keep the reasonable price .
3. We control production quality very strictly to keep ournone compensation record.
4. We guarantee 24 hours response and 48 hours solution provide service.
5. We provide free samples before orders, we accept trail order quantity before regular cooperations.
6. We ensure you get your order delivery in full within the agreed time period
7. Due to our selling power and exporting volumn, we have excellent freight rates with shipping lines.
8. We strive to always be fair and honest in our dealings with customers.
9. We strive to work together with customers to achieve much more than we can achieve alone.
10. We focus on growing business together with all of our customers,Because we understand to take care of our own benefit we firstly need to take care of customer's benefit .
11. Through our passion and commitment we aim to be a market leader in all our key markets. To maintain our position as market leader we must continue to add value in all that we do.
