Prefab Container House Q355 Q235 Steel Frame Sandwich Panel

Large Image : Prefab Container House Q355 Q235 Steel Frame Sandwich Panel

Product Details:

Place of Origin:	CHINA,QINGDAO
Brand Name:	YDX
Certification:	CE ISO SGS
Model Number:	YDX-XF

Payment & Shipping Terms:

Minimum Order Quantity:	10 sets
Price:	$400 - $1000 per square meter
Packaging Details:	Exported standard packing
Delivery Time:	20-30 works days
Payment Terms:	T/T
Supply Ability:	10000 tons/month

Contact Now Chat Now

Prefab Container House Q355 Q235 Steel Frame Sandwich Panel

Description

Keyword:	Mobile Living Container House	Wall:	50mm/75mm Sandwich Panel
Structure:	Steel Frame	Color:	Optional
Function:	Rotproof Waterproof Fireproof	Hvac System:	Air Conditioner/Heater
Storey:	Two Layer	Main Frame::	Q355 Q235
Window：:	Aluminum Alloy Window	Door：:	Sliding Door, Rolling Door
Wall & Roof::	Sandwich Panel; Color Steel Sheet	Secondary Structure：:	Purlin; Brace, Knee Brace Etc
Cladding::	PU/Rock Wool/Fiberglass/EPS	Column & BeamConnection::	High Strength Bolt
Highlight:	Prefabricted Residential Container Homes , Residential Container Homes Q355 , Q235 Container Module House

Prefabricated Residential Container Homes Q355 Q235 Container Module House

Key Features

Mobile living container house with flexible design
Steel frame structure with Q355/Q235 main frame
50mm/75mm sandwich panel walls with optional cladding (PU/Rock Wool/Fiberglass/EPS)
Rotproof, waterproof, and fireproof construction
Includes HVAC system (air conditioner/heater)
Two-layer design with stacking capability up to 3 floors
Aluminum alloy windows and sliding/rolling doors
High strength bolt connections for durability

Attribute	Specification
Wall	50mm/75mm Sandwich Panel
Structure	Steel frame
Color	Optional
Function	Rotproof Waterproof Fireproof
HVAC System	Air conditioner/Heater
Storey	Two layer
Main Frame	Q355 Q235
Window	Aluminum Alloy window
Door	Sliding Door, Rolling Door

Product Advantages

Excellent assembly/disassembly capability with no damage
Flexible lifting, fixing and combination options
Heatproof and waterproof construction
Cost-effective with convenient transportation (4 units fit in one standard container)
10-15 year service life
Optional installation, supervision and training services available

Applications

Ideal for various uses including:

Site offices and living quarters
Meeting rooms and dormitories
Retail shops and storage facilities
Kitchens, shower rooms, and toilets

Technical Specifications

Components	Specification	Note
Wall panel	50mm thick rock wool sandwich panel	Hot-dip galvanized double side color steel 0.3mm
Main steel Frame	Roof Frame	4 beams, 4 corner connectors, 80401.2purlin, 0.45mm steel sheet
Bottom Frame	4 beams, 4 corner connectors, 9 square tube
Pillar	2.0mm 210*150
Gate	Security door	Steel Security door
Window	Aluminum alloy belt anti-theft window	Custom size available

Installation & Performance

6m * 3m * 2.89m flat pack container design
6 workers can install 1 unit in just 2 hours
Stackable up to 3 floors
Pre-installed electrical system with DB, breaker, power inlet & lights
Total-sealed-top & corner-draining system prevents water leakage
Fully welded top frame + truss & bottom frame + supports ensure structural strength
