Q355 Q235 Prefabricated Multi Storey Steel Building Apartment

Q355 Q235 Prefabricated Multi Storey Steel Building Apartment
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment Q355 Q235 Prefabricated Multi Storey Steel Building Apartment

Large Image :  Q355 Q235 Prefabricated Multi Storey Steel Building Apartment

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-00
Payment & Shipping Terms:
Minimum Order Quantity: 1-10000 square meters
Price: $35.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Q355 Q235 Prefabricated Multi Storey Steel Building Apartment

Description
Drawing Design:: AutOCAD /TEKLA Main Frame:: Q355 Q235
Cladding:: PU/Rock Wool/Fiberglass/EPS Secondary Structure：: Purlin; Brace, Knee Brace Etc
Wall & Roof:: Sandwich Panel; Color Steel Sheet Column & BeamConnection:: High Strength Bolt
Window：: Aluminum Alloy Window Door：: Sliding Door, Rolling Door
Highlight:

Q355 Multi Storey Steel Structure Building

,

Multi Storey Prefabricated Apartment Building

,

Multi Storey Prefabricated Apartment Building

Q355 Q235 Multi Storey Steel Structure Building Prefabricated Apartment Building
Product Specifications
Attribute Value
Drawing Design AutOCAD /TEKLA
Main Frame Q355 Q235
Cladding PU/Rock Wool/Fiberglass/EPS
Secondary Structure Purlin; Brace, Knee Brace Etc
Wall & Roof Sandwich Panel; Color Steel Sheet
Column & Beam Connection High Strength Bolt
Window Aluminum Alloy window
Door Sliding Door, Rolling Door
Project Overview
Prefabricated multi storey steel structure construction apartment building located in the Atlantic Ocean near Ghana, Africa.
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 0 Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 1 Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 2 Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 3
The ground floor functions as a garage with 3.3m floor height. Floors two to five are apartments with 3.3m floor height, featuring a floating roof garden design at 3.0m height. The second floor includes one household per staircase with separate dining rooms, available in large (290m²) and small (226m²) configurations.
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 4
Floors three to five feature two households per staircase, with small units at 78.8m² and large units at 147.42m². The design has been improved to maintain original features while meeting all building code requirements.
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 5
Structural Design Features
The ground floor parking area was optimized by adding columns to reduce the original 11.4m span to a more economical 6-9m range, improving structural efficiency while maintaining capacity for 24 domestic vehicles. All staircase corners now feature required load-bearing columns.
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 6
First floor apartments feature optimized room layouts with improved structural walls and functional spaces. Original protruding walls were redesigned to be flush with stairwell walls for better structural integrity and space utilization.
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 7
Floors two to four feature independent apartment units with corrected room layouts to meet building codes, including proper ventilation for kitchens and structural support for balconies.
Q355 Q235 Prefabricated Multi Storey Steel Building Apartment 8
Building Systems
  • Lightning protection system with roof parapet arresters connected to steel columns
  • Solar water heaters on roof supplying all bathrooms
  • Complete electrical systems with LED lighting and waterproof fixtures in wet areas
  • Hybrid solar air conditioning in living rooms and bedrooms
  • Integrated communication systems with phone connections in all units
  • Water storage tanks on roof with ground-level pump house
  • Dedicated generator rooms for each building
  • Hybrid solar/wind power generation system
Engineering Specifications
Structural safety grade: Level 2
Seismic design: Intensity 7 (0.15g acceleration)
Basic wind load: 0.4KN/m²
Floor dead load: 6.0KN/m²
Floor live load: 2.0KN/m²
Roof dead load: 6.0KN/m²
Roof live load: 2.0KN/m² (accessible) / 0.5KN/m² (inaccessible)
Primary structural materials include Q345B low alloy steel square pipes and H-beams, with an average steel usage of 63Kg/m². The building features steel composite floors, cement foam/fiber cement walls, SBS waterproof roofing, and aluminum floating roof panels.
Applications
This pre-engineered steel building technology is ideal for:
  • Multi-storey apartment buildings
  • Factory workshops
  • Warehouse facilities
  • Hangar designs
The bolt-connected design requires no on-site welding, offering 30% weight reduction compared to conventional steel buildings while maintaining structural integrity.

Tag:

Steel Structure Building Construction,

Prefabricated Apartment Building,

High Rise Steel Buildings
