Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings

Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings
Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings
Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings

Large Image :  Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: ISO,BV,CE
Model Number: YDX-S101
Payment & Shipping Terms:
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 10000 tons/month
Contact Now Chat Now

Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings

Description
Door: Sliding Door Or Rolling Door Earthquake Resistance: Strong
Color: Customized Size: Customized
Connection Form: Bolt Connection Transport Package: Standard Sea Package
Secondary Frame: Hot Dipped Galvanized Purlin Structure Type: Frame
Frame Type: Steel Frame Windows: Aluminum
Seismic Design: High Seismic Zone Installation Time: Short
Aesthetics: Modern Construction Type: Frame
Cost: Moderate Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding Roof: Glass Wool, EPS, PU
Product Fire Resistance: Fireproof
Highlight:

Steel Frame Workshop Prefabricated

,

Customized Steel Frame Workshop

,

Metal Frame Prefabricated Workshop Buildings

Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings
Premium Steel Structure Workshop for Auto Service Shops

Our GB Standard-compliant Steel Structure Workshop provides a durable, prefabricated solution for industrial applications. Designed specifically for auto service operations, this steel building offers exceptional stability and strength while requiring minimal maintenance.

Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings 0 Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings 1
Structural Components
Main Steel Frame System
Component Specification
Main structure H section steel Q355, alkyd painting, two primary painting, two finish painting
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Bracing System
Component Specification
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Key Features
  • Customizable colors to match your brand identity
  • Bolt connection for easy assembly
  • Earthquake resistance: Grade 7
  • Standard sea package for safe transportation
  • Frame structure for maximum stability
  • Available with various roof and wall panel options
Technical Specifications
Parameter Value
Connection Form Bolt Connection
Earthquake Resistance Grade 7
Material Steel
Standard GB Standard
Structure Frame Structure
Packaging & Shipping

Our Steel Structure Workshop is carefully packaged in steel pallets for secure transportation. Delivery is typically completed within 30 business days via sea shipping.

Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings 2
Customization Options
Parameter Options
Thermal insulation EPS, fiberglass wool, rockwool, PU sandwich panels or metal steel sheets
Door configuration Custom quantity and size available
Crane support Optional with custom lifting capacity and height
Support & Services

We provide comprehensive technical support for installation and maintenance to ensure optimal performance of your steel structure workshop. Our expert team is available to assist with any technical requirements.

Customized Steel Frame Workshop Metal Frame Prefabricated Workshop Buildings 3
