Customizable Steel Structure Shed with Galvanized C Purlin

Customizable Steel Structure Shed with Galvanized C Purlin
Customizable Steel Structure Shed with Galvanized C Purlin
Customizable Steel Structure Shed with Galvanized C Purlin Customizable Steel Structure Shed with Galvanized C Purlin Customizable Steel Structure Shed with Galvanized C Purlin Customizable Steel Structure Shed with Galvanized C Purlin Customizable Steel Structure Shed with Galvanized C Purlin Customizable Steel Structure Shed with Galvanized C Purlin

Large Image :  Customizable Steel Structure Shed with Galvanized C Purlin

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-CH
Payment & Shipping Terms:
Minimum Order Quantity: 1-10000 square meters
Price: $35.00-$63.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Customizable Steel Structure Shed with Galvanized C Purlin

Description
Material: Steel Insulation: Available
Durability: High Purlin: Galvanized C Section Steel
Door: Sliding Door Or Rolling Door Roof Type: Gable
Connection: All Bolt Connection Size: Customizable
Highlight:

Outdoor Structural Steel Sheds

,

Outdoor Durable Steel Sheds

,

Outdoor Metal Building Storage Sheds

Outdoor Durable Structural Steel Sheds Metal Building Storage Sheds
Product Specifications
Material Steel
Insulation Available
Durability High
Purlin Galvanized C section steel
Door Sliding Door or Rolling Door
Roof Type Gable
Connection All Bolt Connection
Size Customizable
Durable and Practical Outdoor Storage Steel Structure Sheds

Steel structure storage sheds are engineered solutions designed for long-term durability, cost efficiency, and versatile functionality in outdoor environments. These sheds are widely adopted across industries for storing machinery, raw materials, vehicles, and agricultural products.

Key Features
  • Modular Expansion: Bolt-connected components allow seamless addition of sections
  • Natural Ventilation: Ridge vents and louvers for airflow control
  • Solar-Ready Roofs: Pre-installed mounts for photovoltaic panels
  • IoT Integration: Sensors for real-time monitoring of structural conditions
  • High-strength steel frames (yield strength ≥ 345 MPa)
  • Hot-dip galvanized coatings for corrosion resistance
  • Wind resistance up to 200 km/h
  • Snow load capacity up to 2.0 kN/㎡
Material Specifications
Component Material Type Key Properties Lifespan
Primary Framework Hot-rolled steel (S355JR grade) High tensile strength (470-630 MPa), weldability, and impact resistance 50+ years
Cladding Galvalume® sheets (AZ150) Aluminium-zinc alloy coating for UV and corrosion resistance 30-40 years
Insulation PIR foam-core panels (100mm) Thermal conductivity ≤ 0.022 W/m*K, fire-resistant (Class A1) 25+ years
Fasteners Stainless steel (Grade 316) Resistance to saltwater and chemical corrosion 40+ years
Structural Components
Component Description
Primary Framing Box beam column, cross steel column, H-shaped steel column, steel beam
Secondary Framing Galvanized Z and C sections purlin
Roof and Wall panels Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU)
Steel Decking Floor Galvanized steel decking board
Structural subsystem Divider, gutter, awning, partition wall
Customizable Steel Structure Shed with Galvanized C Purlin 0 Customizable Steel Structure Shed with Galvanized C Purlin 1
Technical Specifications
Parameter Specification
Service Life 50-70 years
Place of Origin Qingdao, Shandong, China
Application Workshop, warehouse, poultry house, garage etc
Grade Q235B, Q355B or as per customer's need
Bolt Grade M20, M16, M14 etc
Customization Options
  • Customized design available based on your requirements
  • Various door options: sliding or rolling doors
  • Multiple panel options: EPS/PU/fiber glass/rock wool
  • Flexible window options: PVC steel or aluminum alloy
  • Custom downspout materials available
Our Services
  • Custom design plans and accurate quotations
  • Professional engineering support
  • Comprehensive services including design, manufacturing, installation and after-sale service
  • Optional installation guidance and supervision
  • Quality control with ISO 9001 standards
Quality Assurance
  • Professional QC team monitoring all manufacturing stages
  • Accept third party international inspection agencies (SGS, BV etc.)
  • Weekly quality audit meetings
  • Bi-weekly employee training
  • Monthly client feedback collection

Tag:

Steel Outdoor Storage Shed,

Metal Storage Sheds,

Steel Frame Storage Shed
