Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse

Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse

Large Image :  Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-DJ
Payment & Shipping Terms:
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse

Description
Application:: Metal Building Frame Structure Warehouse Usage:: Steel Structure Workshop, Metal Warehouse, Factory Buildings, Garment Factory
Type:: Prefabricated Steel Frame Buildings Surface Treatment:: Painting Or Hot-dip Galvanize
Wall And Roof:: Steel Cladding Columns And Beam:: H Section Column&Beam
Structure Type: Frame Frame Type: Steel Frame
Earthquake Resistance: Strong Windows: Aluminum
Seismic Design: High Seismic Zone Installation Time: Short
Aesthetics: Modern Construction Type: Frame
Cost: Moderate Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding Roof: Glass Wool, EPS, PU
Product Fire Resistance: Fireproof Door: Sliding Door Or Rolling Door
Highlight:

Prefabricated Metal Frame Structure

,

Steel Building Metal Frame Structure

,

Metal Building Frame Structure

Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse
Our prefabricated steel frame buildings are ideal for warehouses, workshops, and industrial facilities. With a construction floor area of approximately 3200 square meters, these structures feature welded steel beams & columns, crane systems, steel cladding sheets, purlins, windows, doors, and other accessories.
Comprehensive Steel Structure Services

We specialize in both light and heavy steel structure projects, offering complete services including:

  • Custom design and engineering
  • Fabrication of all steel structure components
  • Insulation panel production
  • Professional on-site installation
Building Components
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse 0
Main steel frame structure
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse 1
Laying purlin
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse 2
H section steel column
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse 3
End wall
Component Specifications
Primary Framing Box beam column, cross steel column, H-shaped steel column, steel beam
Secondary Framing Galvanized Z and C sections purlin
Roof and Wall panels Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU)
Steel Decking Floor Galvanized steel decking board
Structural subsystem Divider, gutter, awning, partition wall
Mezzanines, Platforms Painted or galvanized H beam
Other Building Accessories Sliding doors, roll up doors, aluminium windows, louvers, etc.
Technical Specifications
Service Life 50-70 years
Place of Origin Qingdao, Shandong, China
Application Workshop, warehouse, poultry house, garage etc.
Grade Q235B, Q355B or as per customer's need
Bolt Grade M20, M16, M14 etc
Connection Intensive bolt, ordinary bolt
Window PVC steel or aluminum alloy
Downspout PVC pipe or as per customer's request
Main Frame Welded or hot rolled H-shaped steel, columns, beams, box beams and columns
Custom Design & Quotation
  • Customized designs available to meet specific requirements
  • For accurate quotation and drawings, please provide:
    • Building dimensions (length, width, eave height)
    • Local weather conditions
Why Choose Our Steel Structures?
  • Cost-effective: Professional design reduces construction time and material costs
  • Eco-friendly: Specialized cladding materials provide excellent insulation; recyclable materials
  • Comfortable: Spacious interiors with wide bays and elegant profiles
  • Quality assurance: "Quality first, Customer first" company principle
  • Proven track record: Many customers have established long-term cooperation
Packing & Loading

All structural components, panels, bolts, and accessories are packed securely for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to load goods carefully at our factory loading site to prevent damage.

Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse 4
Project Requirements Form
1. Location (where will be built?) _____country, area
2. Size: length*width*height _____mm*_____mm*_____mm
3. Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4. Snow load (max. snow height) _____kn/m2, _____mm
5. Anti-earthquake _____level
6. Brickwall needed or not If yes, 1.2m high or 1.5m high
7. Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be used (lower cost)
8. Door quantity & size _____units, _____(width)mm*_____(height)mm
9. Window quantity & size _____units, _____(width)mm*_____(height)mm
10. Crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
