Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span

Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span
Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span
Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span

Large Image :  Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-QWE
Payment & Shipping Terms:
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span

Description
Frame Type: Steel Frame Color: Customized
Construction: Steel Frame Fire Resistance: Highly Fire Resistant
Dimension: Customers' Requirement Product Usage: Building Construction
Aesthetics: Modern Drawing Design: AutoCAD,PKPM,3D3S,
Structure Type: Frame Earthquake Resistance: Strong
Windows: Aluminum Seismic Design: High Seismic Zone
Installation Time: Short Construction Type: Frame
Cost: Moderate Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding Roof: Glass Wool, EPS, PU
Product Fire Resistance: Fireproof Door: Sliding Door Or Rolling Door
Highlight:

Pre-engineered Steel Structure Warehouse

,

Q355B Steel Structure Warehouse

,

Q235B Steel Structure Warehouse

Pre-engineered Steel Structure Warehouse With Q355B / Q235B Frame
Key Specifications
Attribute Value
Frame Type Steel Frame
Color Customized
Fire Resistance Highly fire resistant
Dimension Customers' Requirement
Earthquake Resistance Strong
Seismic Design High Seismic Zone
Finish Galvanized/Painted/Cladding
Roof Glass Wool, EPS, PU
Door Sliding Door or Rolling Door
Product Features
  • Precisely engineered steel frame with state-of-the-art welding for exceptional strength and alignment
  • Superior quality roof insulation maintains stable indoor climate
  • Robust steel walls resist dents and scratches while maintaining appearance
  • Fire-resistant coatings for enhanced safety
  • Flexible layout with wide doors for easy loading/unloading
  • Bolt connection system - no welding required on site
  • Up to 30% lighter than conventional steel buildings
Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span 0
Technical Specifications
Component Specification
Main Steel Frame Q345B (S355JR) or Q235B(S235JR) welded/hot rolled H section steel
Supporting System C or Z Section Steel (Q235B) for roof and wall purlins
Roof & Wall System Single colorful corrugated steel sheet (0.3-0.8mm) or sandwich panels (50-150mm)
Accessories Sliding/rolled doors, aluminum/PVC windows, stainless steel ventilators
Key Advantages
  • Cost-effective with attractive appearance
  • High safety performance
  • Easy to assemble and dismantle
  • Manufactured under ISO9001 quality control system
  • Professional installation guidance
  • Environmentally friendly
Production Capabilities

Our factory features three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines, and advanced profiling equipment including plasma cutting machines.

Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span 1
Quality Control
  • Raw Materials: Thickness tolerance <0.25mm, yield and tension strength testing
  • Fabrication: 100% dimension testing (<1mm tolerance), 20% ultrasonic welding tests
  • Surface Treatment: Shot blasting grade Sa. 2.5, paint primer within 5 hours
  • Packing: Standard ocean transportation packaging in 40'HQ containers
Pre-engineered Steel Warehouse with Q355B Frame 400-1500mm Span 2
Project Requirements

Please provide the following information for accurate quotation:

Item Details Needed
1 Location (country, area)
2 Size: length × width × height
3 Wind load (max. wind speed)
4 Snow load (max. snow height)
5 Earthquake resistance level
6 Brick wall requirements (if any)
7 Thermal insulation requirements
8 Door quantity & size
9 Window quantity & size
10 Crane requirements (if any)
