Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin

Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin
Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin
Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin

Large Image :  Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-SD
Payment & Shipping Terms:
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin

Description
Features: Steel Frame Warehouse Purlin: C Or Z Section Galvanized Steel
Structure Type: Frame Sustainability: High
Service Offered: Design, Fabrication, Packing, Transport Longevity: Long-lasting
Intensity: High Intensity Application: Warehouse
Aesthetics: Modern Design Options: Versatile
Customization: Available Roof And Wall: Steel Sheet Or Insulated Sandwich Panel
Cladding: PU/Rock Wool/Fiberglass/EPS Connect: Bolt/Weld
Frame Type: Steel Frame Earthquake Resistance: Strong
Windows: Aluminum Seismic Design: High Seismic Zone
Installation Time: Short Construction Type: Frame
Cost: Moderate Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding Roof: Glass Wool, EPS, PU
Product Fire Resistance: Fireproof Door: Sliding Door Or Rolling Door

Prefab Steel Structure Warehouse with Light Steel Frame

Our prefabricated steel structure buildings are designed for warehouse and workshop applications, offering durability, versatility, and modern aesthetics.

Key Attributes
Purlin C or Z Section Galvanized Steel
Structure Type Prefabricated
Sustainability High
Service Offered Design, Fabrication, Packing, Transport
Longevity Long-lasting
Intensity High Intensity
Application Warehouse
Design Options Versatile
Customization Available
Structural System
  • Transverse structural system: Trusses (roof trusses, beams, and columns) that withstand roof loads, wind, earthquakes, and crane operations
  • Longitudinal structural system: Columns, inter-column supports, and wall beams forming a rigid space skeleton
Material Specifications
Component Specification
Steel Frame H section steel | Q235/Q345 steel 8mm/10mm
Welding Automatic submerged arc welding
Rust removal Sand blasting
Surface finish Alkyd paint or galvanized
Intensive bolt M20, Grade 10.9
Supporting System Angle brace: L50x4, Steel Q235, processed and painted
Roof Components Purlin: C160*60*2.5, Steel Q235, galvanized and painted
Roof panel: Sandwich panel or corrugated steel sheet
Sky light: 6mm thick PVC
Wall Components Purlin: C160*60*2.5, Steel Q235, painted
Wall: Sandwich panel or corrugated steel plate
Accessories Glass cement, self-tapping screws, ventilation ball, doors & windows
Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin 0
Technical Advantages
  • Complete design done at factory with components brought to site for assembly
  • All bolt connections - no welding required on site
  • Up to 30% lighter than conventional steel buildings
  • Reduced steel usage translates to cost savings
Our Services
  • Structural steel fabrication, painting, galvanizing, and pre-assembly
  • Complete design, fabrication, and installation of prefabricated steel structures
  • Detailed fabrication drawings based on your architectural plans
  • Professional engineering consulting services
Prefab Steel Warehouse with Light Steel Frame and Galvanized Purlin 1
Quotation Requirements

Please provide the following information for an accurate quote:

Item Details Required
1 Location (country, area where building will be constructed)
2 Building dimensions (length × width × height in mm)
3 Maximum wind load (kn/m², km/h, or m/s)
4 Maximum snow load (kn/m² or mm)
5 Earthquake resistance level required
6 Brick wall requirements (height if needed)
7 Thermal insulation specifications (material preference if needed)
8 Door quantity and dimensions (width × height in mm)
9 Window quantity and dimensions (width × height in mm)
10 Crane specifications (quantity, max lifting weight in tons, max height in meters if needed)
