Prefab Steel Warehouse with Glass Wool Panels

Prefab Steel Warehouse with Glass Wool Panels
Prefab Steel Warehouse with Glass Wool Panels
Prefab Steel Warehouse with Glass Wool Panels Prefab Steel Warehouse with Glass Wool Panels Prefab Steel Warehouse with Glass Wool Panels Prefab Steel Warehouse with Glass Wool Panels Prefab Steel Warehouse with Glass Wool Panels Prefab Steel Warehouse with Glass Wool Panels

Large Image :  Prefab Steel Warehouse with Glass Wool Panels

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-SD
Payment & Shipping Terms:
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Prefab Steel Warehouse with Glass Wool Panels

Description
Material: Steel Window: PVC, Aluminum Windows
Resistance: Corrosion, Fire, Termites Toughness: Good Toughness
Typical Model: Single Span ,Multi Span Highlight: Painted Steel Structure Warehouse
Installation: Fast Windows: Aluminum
Product Usage: Building Construction Product Material: Steel Structure
Cost: Moderate Technique: Hot Rolled
Steel Grade: Q235B Q345b Low Carbon Steel Versatility: Flexible
Structure Type: Frame Frame Type: Steel Frame
Earthquake Resistance: Strong Seismic Design: High Seismic Zone
Installation Time: Short Aesthetics: Modern
Construction Type: Frame Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding Roof: Glass Wool, EPS, PU
Product Fire Resistance: Fireproof Door: Sliding Door Or Rolling Door
Highlight:

prefab steel warehouse with insulation

,

steel frame building with glass wool

,

prefab warehouse with glass wool panels

Prefab Steel Structure Warehouse with Glass Wool Sandwich Panels
Product Attributes
Material Steel
Window PVC, Aluminum Windows
Resistance Corrosion, Fire, Termites
Toughness Good Toughness
Typical Model Single Span, Multi Span
Highlight Painted Steel Structure Warehouse
Installation Fast
Product Usage Building Construction
Product Material Steel Structure
Cost Affordable
Technique Hot Rolled
Steel Grade Q235B Q345b Low Carbon Steel
Versatility Flexible
Key Features
  • Attractive design with beautiful and elegant appearance using color steel sandwich panels
  • Lightweight construction for convenient shipping and handling
  • Easy assembly and dismantling with simple tools (plugs and screws)
  • Sturdy steel frame structure with sandwich panels for durability
  • Completely waterproof construction
  • Customizable roof, wall, doors, and windows to meet specific requirements
  • Long-lasting anti-corrosion coating on steel frame parts for 50+ years of service
Product Specifications

Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse.

A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!

An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.

Technical Specifications
Component Specification
Main Structure - Column Q355/Q235 H-steel, Box column available
Main Structure - Rafter, Beam Q355/Q235 H-steel
Surface Processing Options 1. Epoxy zinc-rich primer + epoxy mica intermediate paint (120 μm thickness)
2. Hot dip galvanization
Sub Structure - Purlin Q355B, C/Z steel section, galvanization 275g/m²
Sub Structure - Angle brace Q235B, L-steel
Sub Structure - Cross bracing Q235B round bar, L-steel
Sub Structure - Tie bar Q235B, round pipe
Sub Structure - Batter brace Q235B, round bar
Roof System - Panel Options 1. Insulated sandwich panel (PU, rock wool, glass fiber, EPS) with steel sheets (50mm/75mm/100mm thickness)
2. Steel plate (0.4mm/0.5mm thickness)
Wall System - Panel Options 1. Insulated sandwich panel (PU, rock wool, glass fiber, EPS) with steel sheets (50mm/75mm/100mm thickness)
2. Steel plate (0.4mm/0.5mm thickness)
3. Brick wall (provided by client)
Prefab Steel Warehouse with Glass Wool Panels 0 Prefab Steel Warehouse with Glass Wool Panels 1 Prefab Steel Warehouse with Glass Wool Panels 2
Frequently Asked Questions
What is the derust grade for the steel structure?

For the main steel structure, the derust grade is ball blasting Sa 2.5, and manual derust St2.0 on secondary steel structure.

How is the installation process handled?

We provide detailed construction drawings as a manual to guide you through the building erection and installation process step by step.

What are the common types of industrial buildings?

Portal frame is widely used for industrial workshops, office buildings, shopping malls and warehouses. Other types can be designed and manufactured according to customer requirements.

What maintenance is required?

Painting touch-ups should be done after frame installation to ensure the surface remains protected for extended periods.

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
