Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone

Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone
Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone
Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone

Large Image :  Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone

Product Details:
Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-DSL
Payment & Shipping Terms:
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Packaging Details: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Contact Now Chat Now

Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone

Description
Seismic Design: High Seismic Zone Working Scope: Design,Fabrication, Installation
Application: Warehouse Structure Type: Frame
Manufacture: Customized Product Durability: High
Product Usage: Building Construction Height: Customized
Insulation: Good Roof: Glass Wool, EPS, PU
Apply: Easy To Apply Installation Time: Faster Construction Time
Corrosion Resistance: Hot-dipped Galvanizding Value: High
Frame Type: Steel Frame Earthquake Resistance: Strong
Windows: Aluminum Installation Time: Short
Aesthetics: Modern Construction Type: Frame
Cost: Moderate Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding Product Fire Resistance: Fireproof
Door: Sliding Door Or Rolling Door
Highlight:

custom hot rolled steel frame

,

warehouse building steel frame

,

high seismic zone steel building

Hot Rolled Steel Frame Warehouse Construction
Product Attributes
Attribute Value
Seismic Design High Seismic Zone
Working Scope Design, Fabrication, Installation
Application Warehouse
Structure Type Frame
Manufacture Customized
Product Durability High
Product Usage Building Construction
Height Customized
Insulation Good
Roof Glass Wool, EPS, PU
Apply Easy to Apply
Installation Time Faster construction time
Corrosion Resistance Hot-dipped Galvanizing
Value High
Key Advantages
  • High quality, strong, durable and stable construction with aesthetic appeal
  • Modular-specific design for efficient assembly
  • Fast and easy erection and installation process
  • Lower cost and maintenance compared to traditional construction methods
  • Excellent waterproof and flameproof properties
  • Extended lifespan compared to similar products
  • Environmentally friendly - steel components are reusable
  • Consistent, uniform quality throughout
  • Economical transportation and handling
  • Professional installation team available
  • Integrated engineering solutions available
Supply Details

Supply Ability: 500 Ton/Tons per Month

Packaging: All load in 40 HQ or according to customer requirements

Port: QingDao

Lead Time: Shipped within 30 days after payment

Technical Specifications
Component Specification
Size Custom width, height, length and roof slope
Steel grade Q235B or Q345B carbon steel and alloy steel
Column and beam Hot rolled or high-frequency welding H-section steel
Purlin Hot galvanized C/Z section steel, size of C100-C320, Z160-Z300
Brace X or V or other type bracing made of angle steel, round bar
Roof and wall EPS/PU/Glass wool sandwich panel, steel colour sheet
Door Rolling shutter, lift door, steel door, glass door, fire-proof door
Window PVC / aluminum alloy window / plastic steel window
Connection Bolts/ welding / riveting
Crane Customizable up to 200T capacity
Surface treatment Hot dip galvanized or painting
Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone 0
Product Application

Light Frame Steel Construction for hangars, prefabricated steel structures, factory buildings, and workshops.

Pre-engineered steel buildings feature factory-designed components that are assembled on-site with bolt connections, eliminating the need for welding. These structures can be up to 30% lighter than conventional steel buildings, resulting in material savings and cost efficiency.

Detailed Specifications
System Component Specification
Main Steel Frame Steel Column & Beam Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
Surface: Hot Dip Galvanized or Painted
Connection: All Bolts Connection
Supporting System Roof Purlin: C or Z Section Steel, Q235B
Wall Purlin: C or Z Section Steel, Q235B
Bracing: Steel Rod, Q235B
Cross Support: Steel Rod, Q235B
Column Support: Angle Steel; Steel Rod; Q235B
Angle Brace: Angle steel,Q235B
Tie Bar: Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet; Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU; Thickness: 50-150mm
Accessories Door: Sliding; Rolled Up Door (Manual/Auto)
Window: Aluminum Alloy; PVC
Downspout: PVC pipe
Gutter: Galvanized Steel Sheet; Stainless Steel
Ventilator: Stainless Steel Turbine Ventilator
Skylight Belt: FRP or PC semi-transparent Skylight Belt
Flash: Color Steel Sheet
Fittings: Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail
Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone 1
Packaging and Transportation
Custom Hot Rolled Steel Frame Warehouse Building High Seismic Zone 2
Frequently Asked Questions
What kind of Industry Steel Workshop do you need?

Our experienced engineers can design buildings to your exact specifications. We take your building investment as seriously as you do.

Are you manufacturer or trade company?

We are professional manufacturers of steel structure buildings.

Do you offer guiding installation on site overseas for warehouse building?

Yes, we provide installation guidance, supervision, and training services. Our engineers can be dispatched to your location, and we provide detailed installation drawings with 24-hour online support.

What's the quality assurance you provided and how do you control quality?

Our professional QC team monitors quality at all manufacturing stages. We accept third-party inspections from agencies like SGS and BV.

Could you offer designing service?

Our complete engineering team uses advanced design software (Tekla, AutoCAD, PKPM, etc.) to provide economical solutions at no extra cost for preliminary designs.

Is there any warranty available on the steel structure buildings?

Our steel structures come with limited warranties and can last 50-100 years depending on materials, design, construction quality, and maintenance.
